Sauce Filling Machines And Production Line For Chili Sauce /Tomato Sauce/Bbq Sauce Bottled Filling Machine

Sauce Filling Machines And Production Line For Chili Sauce /Tomato Sauce/Bbq Sauce Bottled Filling Machine

The automatic chili sauce sauce filling production line integrates light, machine, electricity and gas. It adopts the piston quantitative principle, with high filling precision, simple operation and convenient maintenance.

Thick Sauce Filling  Machine Characteristic:

This product is mainly composed of automatic filling machine-automatic capping machine-labeling machine, which is ideal for medium and high-capacity seasoning manufacturers.

Scope of application: It is the biggest advantage of this automatic chili sauce sauce filling line, which can fill almost all sauces and sauces, including large meat sauce, granule sauce, thick sauce, bean paste, sweet sauce, chili sauce and so on.

DONGTAI can provide a wide variety of filling machine such as liquid filling machine, sauce filling machine, powder filling machine and granule filling machine.  Our products have high quality and competitive prices.

For more information on packaging machines, please click here.

https://www.ltete.com/

Semi-automatic granular sauce filling machine for caviar,shrimp paste

Semi-automatic granular sauce filling machine for caviar,shrimp paste  Sauce Filling Machine

Semi - automatic sauce filling machine SFM series is reasonable in structure, compact in size, reliable in performance, accurate in quantity and convenient in operation. The machine is 304 stainless steel, filling head anti leakage anti dripping oil, air cylinder drive structure, increase 200L hopper, brand aluminum shell copper core high power mixing motor, frequency conversion speed control, PLC intelligent control, the user can according to the need to adjust the filling volume and filling speed, filling precision is high.

Characteristic:

Semi-automatic granule filling machine Technical Parameters:

metering method	Plunger pump volume metering
Filling Volume	100ml-500ml
Filling speed	≤20Bottle/min
Filling accuracy	±1.5%
Power	0.8KW
Bottle Height	30-180（mm）(customized)
Apply the bottleneck	30-80（mm）(customized)
product size	1200（L）*800（W）*620（H）mm(customized)

The seven Principle Features:

1.The machine as semi-automatic piston filler can fill particulate slurry fluid material.
2.The machine is reasonable in design, compact in model, vertical structure, saving space, easy to operate.
3. Pneumatic part is made of Germany FESTO and Taiwan AirTac pneumatic components.
4. Material contact parts are used 304L stainless steel material, meeting the food standard.
5. Filling valve controlled by the pneumatic valve, more accurate.
6. Filling volume and filling speed can be adjusted arbitrarily.
7. Filling head adopts anti-lift filling device.

DONGTAI can provide a wide variety of filling machine such as liquid filling machine, sauce filling machine, powder filling machine and granule filling machine.  Our products have high quality and competitive prices.

For more information on packaging machines, please click here.

https://www.ltete.com/

Magnetic Pump Liquid Filling Machine

Magnetic Pump Liquid Filling Machine  Liquid Filling Machine Peristaltic Pump Filling Machine

Characteristic:

Our magnetic pump liquid filling machine adopts world brand frequency converter, equipped with imported high-accuracy multi-turn potentiometer and lockable dial, which makes the flow regulation stable and accurate, the error negative deviation is less than 0.5%, and the positive deviation is less than 1.5%.

Japan imported magnetic gear stainless steel pump, reliable quality and long life.

Stainless steel case which is Durable.

Small size and easy to operate.

Easy to clean and disinfect.

Full-featured. Two model automatic and manual. Can be used with the assembly line.

Can be equipped with multiple filling heads, commonly used models are: single pump, double pump and four pump.

The filling volume of SF-II can be adjusted from 1ml to 10000ml; SF-I is adjustable from 10ml to 800000ml, and the adjustment is convenient and easy.

Peristaltic Pump Filling Machine Main Technical Parameters:

We have strict material selection, strict production process, and try our best to make the best of the details.

01.Magnetic pump - pump head

Imported 316L stainless steel pump head, fast speed, high accuracy, corrosion resistance, acid and alkali resistance, in line with pharmaceutical grade requirements;

02.All stainless steel body

The body is made of stainless steel clean and easy to clean

03.Microcomputer control panel

Imported control 4-bit cursor control board.precise control. Intuitive and simple operation，small error.

04.Medical grade silicone tube

It adopts medical grade silicone tube which is more suitable for food grade requirements corrosion resistant.glass ball valve with feeding port and can be filtered to prevent backflow.

DONGTAI can provide a wide variety of filling machine such as liquid filling machine, sauce filling machine, powder filling machine and granule filling machine.  Our products have high quality and competitive prices.

For more information on packaging machines, please click here.

https://www.ltete.com/

Semi-Automatic Single Head Liquid Filling Machine

Semi-Automatic Single Head Liquid Filling Machine     Semi-automatic Oil Filling Machine

Main Technical Parameters:

01.Stainless steel  Replaceable nozzle

Wide application Long lifetime

02.imported cylinders

High load inlet cylinder

This machine adopts well-known brand cylinders with high power, stable air pressure and durability.

03.High quality detachable buckle button for one-touch removal

Liquid products such as beverages and drinks no need for screw removal easy to clean.save time and effort.

04.Barometer  High resolution Easy to operate, stable performance

05.The 3-way valve

Stainless steel three-way valve

Easy to operate smooth delivery

Filling Machine  Packaged product

Wide range of application

Widely used the pharmaceutical,chemical,food,beverage,oil,cosmetics and other industries.

DONGTAI can provide a wide variety of filling machine such as liquid filling machine, sauce filling machine, powder filling machine and granule filling machine.  Our products have high quality and competitive prices.

For more information on packaging machines, please click here.

https://www.ltete.com/
